ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals

Short Description:

Product Feature: High Quality Performance Professional Ultrasound Scanning Probe with Best Price with 12" Screen for Animal and Human Diagnosis with Medical Ultrasound Equipment for Abdominal, Obstetrics, Gynaecology, Urology, Cardiology, Small Parts with Multiple Imaging Mode B 2b 4b M B/m Pw Mode, can also be used for veterinary ultrasound, optional probe convex linear transvaginal

Send email to us

Product Detail

Product Tags

Overview

Quick Details

Place of Origin:

China

Brand Name:

Amain

Model Number:

ZONCARE-i50

Power Source:

Electric

Warranty:

2 years

After-sale Service:

Online technical support

Material:

Metal, Plastic

Shelf Life:

2 years

Quality Certification:

CE ISO

Instrument classification:

Class II

Safety standard:

None

Imaging mode:

B, 2B/4B, M, B/M, PW

Display:

12 inch color display screen

Transducer connectors:

2 transducer connectors

Resolution:

1024 *768

Tile Angle:

0-90°

Voltage:

100-240V~

Frequency:

50/60Hz

Gain:

Adjust the whole image gain value

Save:

Save image/report

Dimension:

37*36*15.5 cm

ZONCARE Medical Ultrasound Instruments Outstanding Portable Veterinary Ultrasound Scanner for Animals

Specification

item	value
Model	ZONCARE-i50
AC adapter Input	Voltage: 100-240V~ Frequency: 50/60Hz Power Consumption: 320VA
Built-in Battery	Lithium-ion rechargeable battery: 18650/6200mAh/66.9Wh Nominal voltage: 10.8V Limited charging voltage: 12.6V
Imaging mode	B, 2B/4B, M, B/M, PW
Display	12 inch color display screen
Transducer ports and holders	2 transducer ports 2 removable transducer holders
Clinical Applications	Abdomen, Obstetrics, Gynecology, Urology, Cardiology, Small Parts, Blood Vessel, Superficial, Thyroid, Galactophore, Custom
Resolution	1024 *768
Tile Angle	0-90°
Voltage	100-240V~
Frequency	50/60Hz
Gain	Adjust the whole image gain value
Save	Save image/report
Transducer Types	Convex transducer, Linear array, Trans-vaginal transducer, Micro-convex transducer
Operation Environment	Ambient temperature: 5 ℃~+40℃ Relative humidity: 25%~85% Atmospheric pressure: 700hPa~1060hPa
Storage &Transport Environment	Ambient temperature: -20 ℃~+55℃ Relative humidity: 10%~95% Atmospheric pressure: 500hPa~1060hPa
Support Language	Chinese, English, Spanish, French
Net Weight	6.2 kg
Dimension	373615.5 cm

Product Application

i50 has excellent performance and different applications according to user's demands: Gynecology, Obstetrics, Abdomen, Urology, Vascular, Small parts, Orthopedic, Interventional etc.

Product Features

Features

●12-inch high resolution medical LCD monitor● Two transducer connectors● Auto-freezing function● Auto-generation BMP format report● Full screen imaging FSI● Q-Guide ● One key data storage● Multiple data transmission● Optional USB foot switch● Optional built-in battery● Optional customized trolley and suitcase● Transducers: Convex, Linear, Transvaginal, Micro-Convex
