Amain AMDV-900 ultrasound manufacturers portable B/W ultrasound machine handheld veterinary ultrasound scanner

Short Description:

Send email to us

Product Detail

Product Tags

Overview

Essential details

Place of Origin:

China

Brand Name:

Amain

Model Number:

AMDV-900

Power Source:

Electric

Warranty:

2 years, 2 years, 24 Months

After-sale Service:

Online technical support

Material:

Plastic, Steel

Shelf Life:

2 years

Quality Certification:

Instrument classification:

Class II

Safety standard:

GB15979-2002

Product name:

Amain laptop/portable B/W ultrasound machine

Application:

OB&GYN, Urology, Abdomen, Small Parts, Cardiology, Vascular ect.

Display:

12 Inch LED Screen

Display mode:

B,2B,4B,BM,M

Weight:

9.7KG

medical ultrasound scanner Scanning mode:

Convex/Linear

Gray scales:

256

medical ultrasound scanner Image storage:

medical ultrasound scanner Video output:

PAL-D , Non interlace , VGA

Product Description

Amain AMDV-900 ultrasound manufacturers portable B/W ultrasound machine handheld veterinary ultrasound scanner

Specification

item	value
Model	Amain AMDV-900
Power Source	Electric
Warranty	2 years
After-sale Service	Online technical support
Material	Plastic, Steel
Shelf Life	2 years
Quality Certification	CE, ISO13485
Instrument classification	Class II
Safety standard	GB15979-2002
Product name	Amain laptop/portable B/W ultrasound machine
medical ultrasound scanner magnification	16 kinds
Scanning mode	convex / linear / micro-convex
Probe	96 elements convex, linear, transvaginal, rectal
Monitor	12 inch high resolution LED
Operation panel	user-friendly, convenient and flexible with back-lit silica gel keyboard& track ball operation
Display mode	B, B+B, 4B, B+M, M
Scanning depth	more than 244mm
Resolution	lateral≤2mm, axial≤1mm
Blind zone	≤3mm
Geometry precision	lateral≤5%, axial≤5%
Gray scale	256
Electronical focusing	2 focuses combination randomly
Cine loop	256 frames, realized in automatic successive playback and manualsingle step forward, backward playback
Permanent image storage	8
Magnification	×0.8, ×0.8, ×0.90, ×0.95, ×1.0, ×1.05, ×1.10, ×1.20, ×1.30, ×1.40,×1.50, ×1.60, ×1.80, ×2.0, ×2.2, ×2.5.(16 kinds)
Body mark	30
Probe interface	2
Pseudo color	7
Image processing	up/ down, left / right, black / white convertion, edge enhancement,gamma correction, frame correlation, pseudo color processor( need external color display)
Measurement	distance, perimeter, area, volume, heart rate, gestational week,FW, AFI, EDD , maternity table, heart package etc
Note	date, time, name, sex, age, doctor, hospital, comment, Chinese/ English conversion
Output interface	PAL-D, SVGA (SVGA color monitor), USB port
Main power supply	AC220V±22V , 50/60Hz

Basic configuration

12 inch high resolution LED3.5MHz Multi-freq Convex Probe(2.5MHz-5.0MHz)USB port

Options6.5MHz Trans-vaginal probe(5.5MHz-7.5MHz)7.5MHz High frequency linear probe(6.5MHz-8.5MHz)7.5 MHz Multi-frequency rectal Linear ProbeTrolley, Printer

Product Application

1.OBSTETRIC2.OB3.GYNECOLOGICAL4.UROLOGY5.SMALL ORGAN

6.Cardiac

…

Product Features

Amain AMDV-900 black and white portable ultrasound system as a high-array, high-definition, multi-function all-digital true 96 yuan laptop ultrasound diagnostic instrument has:

main futures of portable medical pet use ultrasound scanner for obstetrics 1. High-precision full-digital imaging technology, progressive scanning without flickering, delicate and clear images2. 12 inch LED high definition monitor. Only 6.5kg Easy for taking, portable, lighter3. Professional embedded ultrasonic platform4. high density probe, broadband and frequency conversion technology, increase the image quality greatly5. Backlight silica gel keyboard, Photoelectricity track control6. Intellectualized TGC gain control of the whole paragraph8, precisely adjustment image density7. Wide applications: Abdominal, OB/GYN, Urology, Cardiology, Small parts examination etc.8. USB port: storable and readable

General Images

Probes

Multiple probes

convex-probe

Linear probe

Rectal probe

6.5MHz Trans-vaginal probe(5.5MHz-7.5MHz)7.5MHz High frequency linear probe(6.5MHz-8.5MHz)7.5 MHz Multi-frequency rectal Linear Probe

Packing & Delivery

Amain AMDV-900 ultrasound manufacturers portable B/W ultrasound machine handheld veterinary ultrasound scanner which has the cheapest portable ultrasound machine and best ultrasound machine for pregnancy with factory price support OEM/ODM

Packing way: one set in one aluminium box, then packed into standard export carton

1. Professional export wooden box packaging2. All parts are packed and fixed with foam and stretch wrapping film3. Express delivery, such as DHL, TNT, UPS, FEDEX, EMS, door to door, it takes about 5-8 days to arrive, suitable for portable ultrasound machines4. It takes about 5-7 days to arrive at the airport by air, suitable for a large cart ultrasound model.5. By sea to the seaport, it takes about 15-45 days to arrive, the freight is very cheap, suitable for large quantities of machines.

Packing size : 310x270x220mm, GW: 9.7kg, medical ultrasound scanner net weight:6.9kg

Port:Shanghai, China
